Iron Cobra's 01-15 Triumph Lay Down Battery Box Kit

$ 179.00

Update April 1st 2020: We have taken over producing Iron Cobras Parts, we will still continue to make and sell these trays!  We will have at least 10 in stock at a time.

Iron Cobras Lay Down Battery Box Kit For Triumph Bonneville, Thruxton, and Scrambler models from 2001-2015.

Hand built battery box kit eliminates your rear fender and factory air box creating a ultra clean open appearance for your triumph motorcycle. A true bolt on part the box requires no cutting or modification to your bikes frame and mounts into the factory locations.

Kits include the following features:

-Tig welded 5052 aluminum Battery box powder coated texture black

-No cutting or drilling required for install

-Light weight Antigravity 8 cell lithium ion battery (AG-801)

-New longer starter cable

-Powder coated relocation bracket for rear brake reservoir

-K&N pod air filters and breather filter

Battery Specs:

  • Factory battery has 125 cold cranking amps (CCA)/ 10 Amp Hours (AH)
  • 8 cell Antigravity has 240 CCA/ 11 AH

Notes:

-Kit not for use on bike with lowered suspension.

- ***Bonneville owners*** Two up riding is not recommended as the stock shocks are lower on Bonneville's than the Thruxton or Scrambler. We suggest upgrading to shocks off these models or going with taller aftermarket shocks for two up riding as clearance between the wheel and box becomes crucial in this situation. We cannot be held responsible for damage that will occur if this is ignored.

-Kit requires removal of the side stand switch. The only wiring modification required is looping the side stand kill switch to trick the bike into thinking the kickstand is up, this allows the starter to start your bike. Its 2 wires that need to be cut and connected together on the wiring harness and is very simple to do. You can also put a jumper wire into the stock plug on the wiring harness if cutting wires is not for you.

- Fuel injected models must unwrap the electrical tape and extend the connector for the engine speed sensor. This is easy to do and electrical tape should be re applied when finished to protect the loom.

Average install time for any competent mechanic should be under 3 hours start to finish.

Kit does not come with any rear brake light or turn signals or license plate brackets(these get eliminated with the fender once it is removed). With so many options available on the market we leave this up to you and your personal taste.

Many option available in our online store.

Usually ships in 3-5 days
